- 10.24 kWh wall-mount LFP battery system
- 2 x Pytes V5° 5.12 kWh batteries
- VR-BOX-IC wall-mount cabinet
- Remote monitoring and upgrading (optional WiFi)
- Integrated battery heating film
- Batteries: 10-year / 6,000-cycle warranty
Ships by LTL freight. Too large for parcel delivery. Questions on freight? Call (888) 831-0450.
We accept
Two Pytes V5 batteries in a VR-BOX-IC wall cabinet give you 10.24kWh of tidy, wall-mounted storage. It's ideal for partial-home backup, tiny homes, cabins and smaller solar systems.
What's included
- 2× Pytes V5 LiFePO4 battery (5.12kWh each)
- 1× Pytes VR-BOX-IC wall-mount cabinet
Specifications
| Total storage | 10.24kWh |
| Nominal voltage | 51.2V |
| Max continuous output | 200A combined (100A per battery) |
| Self-heating | Yes, below 32°F |
| Cabinet rating | IP20 (indoor) |
| Combined weight | ~272 lbs |
| Warranty | 10-year Pytes battery warranty |
| Manufacturer | Pytes |
|---|---|
| Included | 2 x Pytes V5° battery + 1 x VR-BOX-IC wall-mount cabinet |
| Total Energy | 10.24 kWh (2 x 5.12 kWh) |
| Battery | 51.2 V 100 Ah LFP, 100 A max charge/discharge each |
| Cabinet | Wall mount, IP20, 26.8 x 13.4 x 33.5 in |
| Battery Certifications | UL 9540, UL 9540A, UL 1973, CEC, SGIP |
| Approximate Total Weight | 271.8 lb (2 x 97 lb + 77.8 lb) |
| Battery Warranty | 10 years or 6,000 cycles |
Specifications are from the manufacturer and may change. Questions? Call (888) 831-0450.
Pytes 10 years or 6,000 cycles (whichever first) warranty
| Coverage | V5/V5α/V5α Plus, 70% capacity retained at end of term |
|---|---|
| Start | earlier of invoice date or manufacture date + 6 months |
| How to claim | contact the seller with proof of purchase, defect description, serial number and install date |
Download: Pytes V5° / V5°α / V5°α Plus Terms of Warranty (Americas)
Manufacturer warranties are provided by the manufacturer. Keep your invoice as proof of purchase. Questions about a warranty claim? Call (888) 831-0450.
