- UL 9540 certified LFP wall-mount battery
- 16 kWh per unit, 314 Ah
- Active cell balancing
- Built-in heating for cold climates
- Closed-loop, no-DIP-switch setup with Sol-Max AIO
- Stackable up to 320 kWh (Sol-Max)
- 15-year warranty
Ships by LTL freight. Too large for parcel delivery. Questions on freight? Call (888) 831-0450.
We accept
A 16kWh UL 9540 LFP battery built to pair seamlessly with the Sol-Max all-in-one inverter. It's plug-and-play and closed loop, with no DIP switches or programming. The IP65 enclosure mounts on a wall or the floor, active cell balancing extends its life, built-in heating protects it in the cold, and you can stack up to 20 units for 320kWh. It's backed by a 15-year warranty.
Highlights
- UL 9540 certified LFP with EVE A+ grade cells
- 16kWh per unit, stackable to 320kWh (20 units)
- Active cell balancing (2A) for longer life and peak performance
- Seamless integration: automatic closed-loop communication with Sol-Max inverters
- Built-in heating for cold climates
- IP65, wall or floor mount
- 15-year warranty (register within the first year)
Specifications
| Nominal voltage | 51.2V (46.4–57.6V operating) |
| Capacity / energy | 314Ah / 16.08kWh |
| Nominal charge/discharge | 160A |
| Max discharge | 210A |
| Expansion | Up to 20 units (320kWh) |
| Enclosure | IP65, wall or floor mount |
| Dimensions | 31.50 × 19.69 × 8.94 in |
| Weight | 284 lbs |
| Certification | UL 9540 |
| Warranty | 15 years |
Pair with the Sol-Max custom wiring trough and 4/0 battery cables. Ships by freight.
| Manufacturer | Sol-Max (formerly MidNite Solar) |
|---|---|
| Model Number | MNPowerflo16 |
| Chemistry | LFP (EVE or REPT A+ grade cells) |
| Nominal Voltage | 51.2 V |
| Operating Voltage | 46.4-57.6 V |
| Capacity | 314 Ah |
| Energy | 16,076 Wh |
| Nominal Charge/Discharge Current | 160 A |
| Max Discharge Current | 210 A |
| Cycle Life | 8,000 cycles @ 77°F, 0.5C/0.5C |
| Communication | CAN / RS485 / RS232, PYLON protocol compatible |
| Ingress Protection | IP65, indoor/outdoor |
| Operating Temperature | -4 to 122°F (heating pads below 32°F) |
| Dimensions | 31.50 x 19.69 x 8.94 in (800 x 500 x 227 mm) |
| Weight | 284 lb (128.9 kg) |
| Mounting | Wall or floor |
| Certifications | UL 1973, UL 9540A, UL 9540 |
| Warranty | 15 years |
Specifications are from the manufacturer and may change. Questions? Call (888) 831-0450.
Sol-Max 15-year limited (prorated after year 1) warranty
Manufacturer warranties are provided by the manufacturer. Keep your invoice as proof of purchase. Questions about a warranty claim? Call (888) 831-0450.
